Ceiling-/wall luminaire TRILUX twenty3
Add to selection
General information
Ordercode YESSS
3087-3183
Product code
7640840
EAN code
04018242570560
Product group
Ceiling-/wall luminaire
Brand
TRILUX twenty3
Product specifications
Suitable for suspended mounting
No
Suitable for ceiling mounting
Yes
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Suitable for light line configuration
No
Suitable for workplace according to EN 12464-1
Yes
Lamp type
LED not exchangeable
With light source
Yes
Suitable for number of light sources
1
Lamp holder
Other
Housing material
Aluminium
Housing colour
White
Material cover
Other
Type of grid
None
Voltage type
AC
Nominal voltage
220 - 240 V
Type of control gear
Electronic transformer
With control gear
Yes
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming programmable
No
Dimming RF
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
Light distributor
Other
Light distribution
Symmetric
Light outlet
Direct
Impact strength
IK02
Protection class according to IEC 61140
I
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
No
Rated ambient temperature according to IEC 62722-2-1
25 - 25 °C
Suitable for emergency lighting
No
With movement sensor
No
With light sensor
No
Covering of the luminaire with thermally insulating material possible
Yes
Filament test according to IEC 60695-2-11
650 °C - 30 s
Max. system power
33 W
Colour of light
White
Colour temperature
3000 - 3000 K
Colour rendering index CRI
80-89
Power factor
0.95
Width
625 mm
Height/depth
46 mm
Length
625 mm
Number of poles
3
Conductor cross section
1.5 mm²
Connection type
Push-in clamp
Surface protection housing
Powder coating
Exchangeable control gear
Yes
Dimming DALI-2
No
Colour consistency (McAdam ellipse)
SDCM5
Max. number of luminaires per miniature circuit breaker B16 (MCB)
23
Max. number of luminaires per miniature circuit breaker C16 (MCB)
39
Flickering value Pst LM
0.3
Stroboscope effect value SVM
0.3
Constant light output (CLO)
No
Photobiological safety according to EN 62471
RG0
Colour of light adjustable
Positions
Luminous flux adjustable
Positions
Beam angle adjustable
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Suitable for wall mounting
No
