Heat recovery unit (residential) Itho Daalderop
Add to selection
General information
Ordercode YESSS
3013-5719
Product code
03-00407
EAN code
08713418038870
Product group
Heat recovery unit (residential)
Brand
Itho Daalderop
Product specifications
Housing material
Plastic
Suitable for central heating boiler connection
No
Suitable for wall mounting
Yes
Suitable for floor mounting
Yes
Residential connection, underside
No
Residential connection, left side
No
Residential connection, right side
No
Residential connection, top
Yes
Roof connection, side
No
Roof connection, top
Yes
With thermal overload protection
Yes
Suitable for wireless remote control
Yes
With digital display
No
Nominal duct diameter
125 - 149 mm
With bypass
Yes
Height
916 mm
Width
597 mm
Depth
286 mm
Suitable for ceiling mounting
Yes
Left/right orientation reversible
Yes
Max. air volume at 100 Pa
200 m³/h
Max. air volume at 150 Pa
150 m³/h
Max. air volume at 200 Pa
125 m³/h
Max. air volume at 250 Pa
80 m³/h
Type of motor
Electronically commutated (EC)
Voltage
230 V
Frequency
50 Hz
Number of phases
1
Electrical connection
Connection cable with europlug
Supporting protocol for MODBUS
No
With wired control unit
No
Suitable for wired control unit
No
With zone controller
No
Suitable for zone controller
No
With internal humidity (RH) sensor
No
Suitable for (extra) humidity (RH) sensor
Yes
With internal carbon dioxide (CO2) sensor
No
Suitable for (extra) carbon dioxide (CO2) sensor
Yes
With heating element
No
With constant pressure control
No
With constant volume flow control
No
Type of frost protection
Other
Connections outdoor air side
Insert end
Connections residential side
Insert end
Supply filter according to ISO 16890-1:2016
ISO Coarse
Efficiency supply filter according to ISO 16890-1:2016
45 %
Exhaust filter according to ISO 16890-1:2016
ISO Coarse
Efficiency exhaust filter according to ISO 16890-1:2016
45 %
Weight
12 kg
Fuse size of the device
16 A
Heat recovery by
Cross-counter-flow unit
Housing material quality
Expanded polypropylene (EPP)
Material heat exchanger
Plastic
Thermal efficiency at 70 % air volume at 50 Pa
87.03 %
Degree of protection (IP)
IP20
Energy efficiency class according to 1253/2014/EU
A
With volatile organic compound (VOC) sensor
No
Suitable for extra VOC sensor
No
Operation by app
No
Max. volume flow according to 1254/2014/EU
200 m³/h
Sound power level according to 1254/2014/EU
53 dB(A)
Power consumption at max. air volume at 100 Pa
59.9 W
Suitable for mounting in suspended ceiling
No
Suitable for mounting in an attic
Yes
With wireless remote control
No
With external humidity (RH) sensor
No
