Dimmer Hager
Add to selection
General information
Ordercode YESSS
1711-8580
Product code
85421100
EAN code
04011334375913
Product group
Dimmer
Brand
Hager
Product specifications
Assembly arrangement
Basic element
Method of operation
Push button
Number of modules (module system)
0
App control via Bluetooth
No
Dimming phase cut-on (leading edge)
Yes
Dimming phase cut-off (trailing edge)
Yes
Serial dimmer
No
Type of load
Universal
Substation input
Yes
Light value memory
No
Applicable with button
Yes
Applicable with movement sensor
Yes
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
Yes
Applicable with infrared button
No
Mounting method
Flush-mounted
Type of fastening
Mounting with claw
Material
Other
Material quality
Other
Halogen free
Yes
Surface protection
Untreated
Colour
Other
RAL-number (similar)
0
Transparent
No
Suitable for degree of protection (IP)
IP20
Impact strength
IK02
Nominal voltage
230 - 230 V
Frequency
50 - 60 Hz
Connection type
Screwed terminal
Core cross section
1.5 - 2.5 mm²
Device width
71 mm
Device height
71 mm
Device depth
33.2 mm
Min. depth of built-in installation box
35 mm
Nominal power resistive load
20 - 350 W
Nominal power capacitive load
20 - 200 VA
Max. switching power LED
250 W
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
